14
Take Down and Alley Lights
Alley Lights
Located at the ends of the light bar to provide light to the side of the vehicle.
Stationary Lamps/Takedown Lights
A stationary assembly used for ArrowStik ashing, takedown, and/or work light applications.
The lamps used for either application are either MR11 Halogen or LED. Reference Figure 8.
MR-11 (Halogen)
LED
FIGURE 8
FIGURE 7
Jumpers shown in
default positions
