Code-3 LFAMP User Manual

2IntroductionThe LFAMP is intended for use as a Secondary Acoustical Warning Device for use with your standard Code 3siren. The LFAMP generates a pe

3Status LEDs - A green indicator LED, visible on the front of the LFAMP, indicates that the device is on whenlighted. The green LED will be lighted

4Installation & MountingThe LFAMP Secondary Acoustical Warning Device may be mounted in the trunk or a console near the primarysiren. Ease of ope

5Figure 2, Wiring Diagram, Typical Connectionsfor RLS Amplifier ShownSpecificationsInput Voltage - 10.5 to 16 VDC, negative ground (earth)Operating Cu

6PROBLEMPROBABLE CAUSEREMEDYNO LFAMP OUTPUT.EXTERNAL 15AFUSE BLOWS.A. AMPLIFIER POWER WIRESREVERSED POLARITYB. AMPLIFIER OVERLOADEDNO OUTPUT FROMSPEA

7NOTES

8Revision 0, 06/06- Instruction Book Part No. 11437©2006, Public Safety Equipment, Inc. Printed in USAWARRANTYCode 3, Inc.'s emergency devices a
